Cylinder 60cc 40mm Sachs 50/3 DMP

40mm Cylinder Sachs 50/3

• Cylinder suitable for Sachs 3-speed engines.
• For blower cooled engines.
• Outer diameter cooling fins: 84 mm
• Hole spacing inlet: 32 mm
• Hole pattern cylinder stud: 40 x 50 mm
• For 28 mm exhaust manifold and one M35 x 2 mm exhaust nut.
• Delivery without piston

In order to mount this cylinder on a Sachs 50/2 engine, various adaptation work is required.

We always advise to check and clean the cylinder before installation and to finish the ports in the cylinder with a 1000 grit sandpaper. This way the edges are no longer too sharp, this will considerably extend the life of the cylinder / piston.
